规格/Specification
项目/型号Item/Model	LT3V1-M5		LT3V1-06
位置数/The Poseition Counting	三口二位/Tow-position Three-port
接管口径/Joint Pipe Bore	进气=出气=M5/Air lnlet=Air Outlet=M5	进气=出气=G1/8/Air lnlet=Air Outlet=G1/8
使用流体/Applicable Fluid	干净的压缩空气/Clean and Filtered Air
压力范围/Working pressure Range(Mpa)	0.15-0.8
工作温度/Operating Temperature	5-50℃
最高动作频率/Max.Action Frequ Ency(S)	每秒五次/5Cycle/Sec
接电方式/Wire Form	直接出线式或端子式/Lead Wire or Connector Type
额定电压/Rated Voltage From	AC(V)(24,110,220,380),DC(V)(12,24)
允许电压范围/Operating Voltage Range	±15%
最短励磁时间/Shortest Excitation Time	0.05秒/0.05Second
